                                  FTTX 1GE 1port onu gpon onu gpon Overview:ONT-1GE GPON ONT is one of the GPON optical network unit design to meet the requirement of the broadband access network. It apply in FTTH/FTTO to pro

Featured Products

                                  FTTX 1GE 1port onu gpon onu gpon


ONT-1GE GPON ONT is one of the GPON optical network unit design to meet the requirement of the broadband access network. It apply in FTTH/FTTO to provide the data and video service based on the GPON network.


GPON is the latest generations of access network technology. ITU-T G.984 is the standard protocol of GPON. The GPON standard differs from other PON standards in that it achieves higher bandwidth and higher efficiency using larger, variable-length packets. GPON offers efficient packaging of user traffic, with frame segmentation allowing higher quality of service (QOS) for delay-sensitive voice and video communications traffic. GPON networks provides the reliability and performance expected for business services and provides an attractive way to deliver residential services. GPON enables Fiber To The Home (FTTH) deployments economically resulting to accelerated growth worldwide.


ONT-1GE is based on ZTE high-performance xPON access chip. The chip supposes three mode: GPON/EPON/P2P, comply with the GPON standard of g.984, g.983, 802.3-2005, CTC EPON equipment technical requirements, have good xPON interoperability compatibility.

ONT-1GE provide one GE auto-adapting Ethernet ports. The ONT-1GE features high-performance forwarding capabilities to ensure excellent experience with Internet and HD video services. Therefore, the ONT-1GE provides a perfect terminal solution and future-oriented service supporting capabilities for FTTH deployment. It has good third-party compatibility to work with the third party OLT, such as Huawei/ZTE/Fiberhome/Alcatel-Lucen.


 Fully compatible with ITU-T G.984.1/2/3/4

 Support downlink rate 2.448Gbit/s, uplink rate is 1.244Gbit/s

 Support 32 TCONT, 256 GEMPORT

 Support bidirectional FEC, supports the RS (255, 239) FEC decoding

 Support AES128 encryption and decryption functions with G.984 standard

 Support SBA and DBA bandwidth allocation

 Support PLOAM, embedded OMCI management with G.984 standard

 Support Dying-Gas detection and reporting

 Support rogue ONU detection

 Support GPON energy saving of G987.3 protocol

 Support Tag/Untag Ethernet frame of 802.1 and Q 802.3 standard, support QinQ

 Support CTC2.1, TR156 requirements of flexible tag processing

 Support for flexible flow classification, maximum 520 flow classification rules

 Support link error monitoring and loop monitoring

 Support a variety of multicast forwarding mode, support multicast replication

 Auto-negotiation and manual settings of Ethernet supporting rate, duplex mode

 UNI interface supports STP/RSTP protocol

 Provide QoS guarantees for different priority business through SLA restraining, Policing, queue management scheduling / congestion avoidance, discarding management mode

 Support flow control based on entrance , choose Pause frame reaction pressure to Packet loss for the business beyond

 Support HQoS function
