155M LC Single Mode Single Fiber 60KM SFP Transceiver Module
Product FeaturesUncooled Laser Diode with MQW Structure
InGaAs PIN-TIA Photodiode Receiver
Reach 60 km Transmission Distance on 9/125µm SMF
DUAL Single Mode Transceiver SFP Footprint LC Optical Interface
Compliant With SFP MSA and SFF-8472
Digital Diagnostic Monitoring Interface
Single +3.3V Power Supply
LVPECL Differential Inputs and Outputs
LVTTL Signal Detection Output
Compliant With ITU-T G.957
Compliant With RoHS and Lead Free
Metal Enclosure for Lower EMI
Operating Case Temperature:
Standard: 0 to +70°C
Extend: -20 to +85°C
Industrial: -40 to +85°C
Product Description
Absolute Maximum Ratings
Parameter | Symbol | Min | Typ | Max | Unit | |
Storage Temperature | Tst | -40 | - | +85 | °C | |
Operating Case Temperature |
TC | OFP2 | 0 | - | +70 | °C |
|
|
|
| - |
| °C |
|
|
|
| - |
| °C |
Power Supply Voltage | VCC | 3.1 | 3.3 | 3.5 | V | |
Power Supply Current | ICC | - | - | 300 | mA | |
Data Rate | DR | 0.05 | 1.25 | 1.3 | Gbps | |
| Parameters | Symbol | Min. | Typical | Max | Unit |
| Power Supply Voltage | VCC | 3.135 | 3.3 | 3.465 | V |
| Power Supply Current | Icc | 350 | mA | ||
| Operating Case Temperature | TI | -40 | 25 | 85 | ºC |
| Parameters | Symbol | Min | Max | Unit |
| Power Supply Voltage | V CC | 0 | 3.6 | V |
| Storage Temperature | Tc | -40 | 85 | ºC |
| Operating Case Temperature | TI | -40 | 85 | ºC |
| Relative Humidity | RH | 5 | 95 | % |
| RX Input Average Power | Pmax | -7 | dBm |
