|1 XPON interface,SC single mode single fiber RX 2.488 Gbits/s rate and TX 1.244 Gbits/s(GPON), RX 1.244 Gbits/s rate and TX 1.244 Gbits/s(EPON) rate Fiber type:SC/UPC Optical power:0~4 dBm Sensitivity:-28 dBm safety: ONU authentication mechanism|
|Wavelength(nm)||TX 1310nm,RX 1490nm|
|Fiber connector||SC/UPC connector (SC / APC optional)|
|Down-link data interface||1*10/100/1000M auto-negotiation Ethernet interface, RJ45 interface|
|Indicator LED||4 pcs|
|DC supply interface||input+12V 0.5A|
About purchasing and shipping:
1) Products are in stock. Contact us and you will buy and ship directly.
2) Shipping cost is depend on address and nation. Please contact us to check the further cost.
3) Every carton includes 80 pcs of ONU device (Neutral type). Purchase order started with one carton.
4) Shipping is clearly through express. There will be a little bit delay of status updating. Please be patient. Deliver time is about 5-10 workdays.
5) Please do your best to cooperate with express company to do custom clearance. If it result in any delay or return back, seller do not take any responsiblity.
1) This is XPON ONU/ONT which means it fit with EPON/GPON OLT.
2) Some OLT appears propriatary protocol. that result in incompatible to ONU. (If you need sample or whole set of equipment, please chat with us about the solutions.)
About products and service:
1) Products support both bridge and router.
2) This products is NO branded. If need brand, please chat with us, we support OEM & ODM services
3) Connector: SC/UPC, if need SC/APC, please contact us, we also support.
4) For this model, we have two kind of design, BOSA & SFF. This one is made of BOSA solution ( Chat with us, if you need SFF)
5) Power adaptor originally: EU.Standard (Two round plug). if you need any other standards please note us when you place the order, we will suppy accordingly.
6) Warranty: 1 year.
|Neatural PACKING||1 PCS/Box||80Boxes/CTN||48*43*38CM||16.5KG/CTN|
|Optfocus PACKING||1 PCS/Box||90Boxes/CTN||48*43*38CM||18KG/CTN|
Contact (if you have any questions, please contact us)
