Onu Sticker Sfp Module Optical Transceiver 1310 1490 Onu Gepon Optical Sfp Module
Specifications
Product Features
•Single fiber bi-directional data links asymmetric TX 1244Mbps / RX 2488Mbps GPON ONU application with GPON MAC
function.
•SC/UPC receptacle SFP with GPON ONU MAC inside, "Plug-and-play" via auto-discovery and configuration
•1310nm DFB burst mode transmitter, 1490nm TIA continuous mode receiver
•Single 3.3V power supply
•Digital diagnostic monitor be retrieved by OLT remotely
•SFP MSA compliance
•Low EMI and excellent ESD protection
•Class I laser safety standard IEC-60825 complian
•RoHS compliance
•Complies with SFP Multi-Source Agreement (MSA) SFF-8074i
•Complies with ITUT-T G.984.2, G.984.2 Amendment 1
•Complies with ITUT G.988 ONU management and control interface (OMCI) specification
Application
•Gigabit-capable Passive Optical Networks (GPON)
•The product is an MSA-compliant SFP that incorporates not just the optics for an ONU, but all of the electronics need as well. It is a "PON on a Stick" that an entire FTTH ONU in a slightly oversized SFP. It can be plugged into networking equipment. Allowing the data interfaces on a switch, router, etc. to be customized for different fiber environments and distance requirements.
Specifications
| Model Number | GPON ONU STICKER B+ SFP |
| No. of Fiber | 2. |
| Use | FTTX |
| product name | Gpon ONU STICKER SFP Module |
| Warranty | 3years |
| Data transfer rate | 1.25/2.5Gbps |
| Wavelength | Tx1310/Rx1490 |
| DDM | Optional |
| Fiber Connector | SC |
| Certification | CE RoHS CE |
| CE RoHS | compliant |
| logo | can be customized |
| Application | GPON Network Applications |
Product Features
•Single fiber bi-directional data links asymmetric TX 1244Mbps / RX 2488Mbps GPON ONU application with GPON MAC
function.
•SC/UPC receptacle SFP with GPON ONU MAC inside, "Plug-and-play" via auto-discovery and configuration
•1310nm DFB burst mode transmitter, 1490nm TIA continuous mode receiver
•Single 3.3V power supply
•Digital diagnostic monitor be retrieved by OLT remotely
•SFP MSA compliance
•Low EMI and excellent ESD protection
•Class I laser safety standard IEC-60825 complian
•RoHS compliance
•Complies with SFP Multi-Source Agreement (MSA) SFF-8074i
•Complies with ITUT-T G.984.2, G.984.2 Amendment 1
•Complies with ITUT G.988 ONU management and control interface (OMCI) specification
Application
•Gigabit-capable Passive Optical Networks (GPON)
•The product is an MSA-compliant SFP that incorporates not just the optics for an ONU, but all of the electronics need as well. It is a "PON on a Stick" that an entire FTTH ONU in a slightly oversized SFP. It can be plugged into networking equipment. Allowing the data interfaces on a switch, router, etc. to be customized for different fiber environments and distance requirements.
